Komfort 80 & 200

Komfort movable walls have been designed to give flexibility in the division of spaces.

Both Komfort 80 & 200 are constructed of flat individual or hinged panels designed with the ability to slide and fold to one or both sides within an opening. The Komfort 80 system is a top hung movable acoustic wall, whilst the Komfort 200 system can be supplied in either top hung or floor supported options.

Komfort 80 at a Glance

Dimensions:
Height – up to 6000mm
Panel width – up to 1250mm
Panel thickness – 80mm, 85mm,
93mm & 100mm

Fire ratings:
Class 1, class 0, f30 or f60

Acoustics:
Up to 53dB (Rw)

Weight:
Up to 52 kg/m2

Stacking options:
E Track, Z Track or K Track

Panels:
Panel construction – aluminium frame
Panel edges – exposed or concealed,
SAA or powder coated
Panel type – individual
Pass door panels – full height or single
Inset

Structure:
Suspension method – top hung, no floor track
Seal type – single cam action

Komfort 200 at a Glance

Dimensions:
Height – up to 6000mm
Panel width – up to 900 mm
Panel thickness – 80mm & 85mm

Fire ratings:
N/A

Acoustics:
Up to 52dB (Rw)

Weight:
Up to 38 kg/m2

Stacking options:
Centre fold, end fold or eccentric

Panels:
Panel construction – aluminium frame
Panel edges – exposed or concealed,
SAA or powder coated
Panel type – hinged
Pass door panels – full height only, single or double
Panel finishes – melamine, laminate, veneer, fabric or spray paint

Structure:
Suspension method – floor supported with top guide or top hung
Seal type –fixed top and bottom sweep strips
